PCT-410E Plus

Pressure based controller designed for refrigeration plants that require suction and discharge pressure control.


Featuring 7 outputs of control, 6 digital and 1 analog for variable speed control, in addition 3 inputs, one for pressure transducer (4~20mA), one for temperature sensor and a digital input. Working in pairs, allows to control up to 5 sets of fans and compressors simultaneously. Versatile, it offers 4 operating modes: linear, rotation, capacity or individual.

It has a serial communication for connection to Sitrad.

Evolution line products has a frontal IP-65 protection, Flatec key for easy access, four digits display and exclusive accessories* as the key programmer EasyProg and the protective case Ecase.

* sold separately

Additional information


71 x 28 x 71 mm

Application example

cooling racks
